Ranges
DC Voltage – 200mV/2/20/200/1000V
Accuracy – ±(0.5%rdg+3dgt)
AC Voltage – 200mV/2/20/200/1000V
Accuracy – ±(1%rdg+3dgt)
AC Response – 40Hz ~ 1kHz
DC Current – 2000μA/20/200mA/20A
Accuracy – ±(0.8%rdg+3dgt) on all ranges except
±(1.5%rdg+3dgt) on 2000μa
±(1.0%rdg+3dgt) on 20A
AC Current – 2000μA/20/200mA/20A
Accuracy – ±(1.0%rdg+3dgt) on all ranges except
±(1.5%rdg+3dgt) on 2000μA
±(1.2%rdg+3dgt) on 20A
AC Response – 40Hz ~ 1kHz
Resistance – 200Ω /2kΩ /20kΩ /200kΩ / 2MΩ /20MΩ /200MΩ
Accuracy – ±(0.5%rdg+2dgt) on all ranges except
±(1%rdg+3dgt) on 200Ω
±(1.5%rdg+3dgt) on 20MΩ /200MΩ
Capacitance – 1.999/19.99/199.9nF/1.999/ 19.99/199.9μF
Accuracy – ±(3.5%rdg+5dgt) on all ranges except
±(5%rdg+20dgt) on 1.999nF
Frequency – 19.99/199.9Hz/1.999/19.99/ 199.9KHz
Accuracy – ±(2%rdg+2dgt)
Sp. Function – Audible Continuity, Diode Test, hFE Test
Power – Two 1.5V “AAA” Battery
Low battery is indicated
Battery Life – 200 hours typical
Accessories – One Pair of Test Leads, Carrying Case, Battery (installed), Instruction Manual and Spare Fuse
Dimensions – 170 x 80 x 43mm (approx.)
Weight – 240gms Including Battery (approx.)
